- Handleless door / damped door closing system
- Continuous flow heater for instant coffee and constant brewing temperature
- Aroma brewing technology for full aroma
- Self-cleaning after each draw
- TFT touch display
further details
- Handleless door / damped door closing system
- Continuous flow heater for instant coffee and constant brewing temperature
- Aroma brewing technology for full aroma
- Self-cleaning after each draw
- TFT touch display
- Bezel-less appliance with attached control module
- Preparation of all beverages at the touch of a button
- Personalization function
- 7 light scenarios
- Electronic level control for milk, water and coffee beans guarantees perfect results
Beverage types
- Ristretto / 2 x ristretto.
- Espresso / 2 x espresso.
- Espresso Macchiato / 2 x Espresso Macchiato.
- Coffee / 2 x coffee.
- Americano / 2 x Americano.
- Latte / 2 x latte.
- Latte Macchiato / 2 x Latte Macchiato.
- Cappuccino / 2 x Cappuccino.
- Flat White / 2 x Flat White.
- Milk Foam / 2 x Milk Foam.
- Warm milk / 2 x Warm milk.
- Hot water / 2 x hot water.
Operation
- Door with damped door closing function.
- Operation by rotary knob and TFT touch display.
- Plain text display.
- Personalization function, storage possibility of 8 individualized beverages.
- 4-stage beverage size setting, volume individually adjustable to cup size.
- 8-step coffee strength setting from very mild to extra strong.
- 3-stage coffee temperature setting.
- 10-step hot water temperature setting.
- 4-step coffee-milk ratio adjustment.
- Stepless grind adjustment.
- Height adjustable coffee spout 7-15 cm.
- Easy access to water, milk and bean containers behind the door.
Equipment
- Maintenance-free ceramic disc grinder.
- Separate coffee powder drawer for a second pre-ground coffee type.
- Water pump with 19 bar pressure.
- Double grind and brew for extra strong drinks with single draw.
- In case of double beverage withdrawal, double grinding and brewing process.
- Integrated milk system in the beverage spout.
- Insulated stainless steel milk container for up to 0.5 liters.
- Integrated lighting with LEDs.
- Removable bean hopper with aroma protection lid for 500 g, for easy switching between different bean types.
- Automatic grinding quantity adjustment.
- Removable 2.4 liter water tank.
- Electronic water filter change indicator.
- Electronic level control for drip tray and coffee grounds container.
- Home network integration for digital services (Home Connect) wired via lan (recommended) or wireless via WiFi.
- The use of the Home Connect function depends on the Home Connect services, which are not available in every country. For more information, visit home-connect.com.
Security
Cleaning
- Fully automatic rinsing program when switching on and off.
- Automatic steam cleaning of the milk system after each beverage.
- Automatic cleaning and descaling program.
- Emptying program to prepare the machine for vacation or transport.
- When changing bean type, the empty grinder function is used to remove residues of the previous type from the system.
- Removable brewing unit.
- Coffee grounds container and drip tray dishwasher safe.
- Beverage spout dishwasher safe.
Planning information
- Door stop not changeable.
- Ideal installation height 95 -145 cm (top edge of niche floor).
- Lateral gap between appliance front and furniture front min. 5 mm.
- Distance between furniture body and front surface 21 mm.
- For corner installation, lateral clearances must be provided.
- Door opening angle of approx. 110° (as delivered) - distance to the wall must be at least 350 mm.
- Door opening angle of approx. 155° - distance to the wall must be at least 650 mm.
- Door opening angle of approx. 92° - distance to the wall must be at least 100 mm (spare part no. 00636455).
- Installation in 59 cm standard niche directly above 14 cm high warming drawer.
- lan connection is located at the bottom right in rear view.
- Special accessory (order as spare part):
- ET-No. 17000705 Water filter cartridge
- ET-No. 00311819 Descaling tablets
- ET-No. 00311769 Cleaning tablets
- ET-No. 00636455 Limitation for opening angle 92°
- ET-No. 11015223 Bean container with lid
Connection data
- Total connected load 1.6 kW.
- Connection cable 1.7 m with plug is included in delivery.
- lan cable not included.
- Power standby/display off 0.5 W.
- Power standby/network 2.0 W.
- Time auto standby/display on 30 min.
- Time auto standby/network 30 min.
- Please refer to the instructions in the user manual if you want to turn off the WiFi function.
Product safety information
Manufacturer information:
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
Bayern
München, Deutschland, 81739
www.bsh-group.com
https://www.bsh-group.com
Drop "Shop: DE: Produktseite: LoadBee" could not be rendered:
Syntax error in template "string:{$drop=kkDropperHelper::getActiveDrop()}..." on line 5 "{/ if}" - Unexpected " ", expected one of: "id, name"
-
Product series200 series
-
Controls: electronic
-
Color devicesilver
-
Basic color of the product: silver
-
Type of construction: Fully automatic
-
Control panel materialplastic
-
Doorno
-
Door hinge: Not applicable
-
Connected load: 1600 W
-
Fuse protection: 10
-
Voltage: 220-240 V
-
Frequency: 50/60 TPU00040
-
Approval certificates: , Australia Standards, ce, EAC-Eurasian, G-Mark, Morocco, Ukraine, VDE
-
Length connection cable170 cm
-
Plug type: Schuko/Gardy.w.grounding
-
Device height: 45,5 cm
-
Device width59 cm
-
Device depth42,6 cm
-
Packed unit height54 cm
-
Width packed unit47,8 cm
-
Depth packed product67 cm
-
Minimum niche height44,9 cm
-
Maximum niche height44,9 cm
-
Minimum niche width55,8 cm
-
Maximum niche width55,8 cm
-
Niche depth35,6 cm
-
Net weight: 20,2 kg
-
Gross weight: 22,9 kg
-
Energy intelligent device, can optimize consumption behavior (2017/1369/EU): No
-
Wireless communication possibleyes, built into the device
-
Network broadband technology: Not applicable
-
SIM card slot availableno
-
Communication technology usedwiFi
-
Type of interface for control: lan
-
Remote upgrade possibilityno
-
Possibility of remote update for maintenance: Yes
-
Possibility of voice controlyes, with optional accessories
-
Selectable languages in displayarabic, Chinese, Czech, Danish, Dutch, English, English us, Finnish, French, German, Greek, Hebrew, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Slovak, Slovenian, Spanish, Swedish, Thai, Turkish
-
Serving Size: All cups
-
Water tank capacity: 2.4 l
-
Coffee bean hopper capacity: 500 g
-
Frothing nozzleno
-
Hot water nozzleno
-
Water supplywater tank
-
Coffee preparation systemgrinding system
-
Standby functionyes
-
Safety devicesblocking in case of missing water tank Water tank full, blocking if drip tray full, blocking if. Trester container full, blocking if brewing unit missing Brewing nozzle, blocking if. Milk nozzle blocked, bowl removal blocked, water tank empty blocked
-
Lightingyes
-
Pre-grinding systemno
-
Type of water protection systemno
-
Software update: No
-
Included accessories1 x mounting screws, 1 x measuring spoon, 1 x test strip for water hardness, 1 x insulated milk container, 1 x connection hose to milk nozzle, 1 x milk riser tube
