- Handleless full glass door with electronic door opening.
- Full touch display with stainless steel control ring.
- Light and display reaction when user is recognized.
- Individual and combined operation of microwave and oven.
- Automatic programs and setting recommendations.
further details
- Handleless full glass door with electronic Door opening.
- Full-touch display with stainless steel control ring.
- Light and display reaction when user is recognized.
- Individual and combined operation of microwave and oven.
- Automatic programs and setting recommendations.
- Usable volume 46 liters.
Heating methods / programs
- Microwave operation with 6 power levels: max. 1000, 600, 450, 360, 180, 90 W.
- Oven operation with 9 heating methods:
- Hot air from 30 °C to 230 °C, grill + circulating air from 30 °C to 230 °C, warm up drinks, with max. microwave level, warm up food, from 360 W to 600 W, Drying from 30 °C to 80 °C, low-temperature cooking from 30 °C to 90 °C + microwave, fermenting from 30 °C to 50 °C, keeping warm, with special microwave setting, defrosting from 90 W to 360 W.
- Hot air and grill + circulating air can be freely combined with microwave power levels 450, 360, 180 and 90 W.
- 70 programs (automatic programs and setting recommendations).
- Storage option for up to 30 favorites.
Operation
- Damped, side-opening door with 110 ° opening angle.
- Electronic door opening.
- Full-touch display with control ring.
- 42 display languages available.
- User recognition, distance adjustable.
- Info texts for additional information.
- Animated quick instructions to support device operation.
Equipment
- Innowave (inverter technology) for consistent microwave power.
- Precise temperature regulation with actual temperature display.
- Grill can be switched on briefly in hot air mode for additional Browning.
- Connection for core temperature sensor (oven temperature sensor can be used).
- Programmable automatic door opening at the end of the cooking time to avoid overcooking.
- Timer functions: cooking time, end of cooking time, accumulating cooking time timer.
- Long-term timer.
- Hot air fan rotating on both sides for ideal Heat distribution.
- Optimal visibility of the food thanks to side lighting.
- 2 shelf levels and the possibility of placing the food directly on the cooking chamber floor using suitable accessories.
Selected digital services (Gaggenau Home Connect)
- Door opening via voice assistant.
- Remote control and monitoring.
- Cooking time estimation when using the Core temperature sensor.
Safety
- Child lock to prevent accidental switching on or operation.
- Electronic door lock to prevent accidental opening of the appliance door.
- Safety shutdown.
- Heat-insulated door with triple glazing.
- Housing cooling with Temperature protection.
Cleaning
- Hygienic stainless steel interior with heat-resistant glass base.
- Cleaning aid program.
Planning information
- Provide a niche without a rear wall.
- Door stop cannot be changed.
- Protrusion of the device front to the furniture body 42 mm.
- Front projection for the Pay attention to the opening of side drawers.
- When planning a corner solution, consider the side-opening door and the required minimum distance from the wall.
- Door opening angle of approx. 110° (as delivered) can be reduced to approx. 97° if necessary.
- Connection box must be accessible and provided outside the installation niche.
Connection data
- Total connection value 2.65 kW.
- Connection cable 1.75 m, pluggable.
Product safety information
Manufacturer information:
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
Bayern
München, Deutschland, 81739
www.bsh-group.com
https://www.bsh-group.com
Drop "Shop: DE: Produktseite: LoadBee" could not be rendered:
Syntax error in template "string:{$drop=kkDropperHelper::getActiveDrop()}..." on line 5 "{/ if}" - Unexpected " ", expected one of: "id, name"
-
Product series: Gaggenau Expressive series
-
Air fry function: No
-
Design: Built-in
-
Control: Electronic
-
Material control panel: without Panel
-
Type of installation: Built-in
-
Control elements: Rotating ring illuminated;Touch control;Full metal
-
Type of microwave oven: Combination operation with microwave
-
Cooking space capacity: 46 l
-
Door stop: Right
-
Max. Microwave power: 1000 W
-
Color of device: Stainless steel behind smoked glass
-
Basic color of the product: Not applicable
-
Color / material of oven door: Stainless steel behind smoked glass
-
Material of viewing window: Glass
-
Connection load: 2650 W
-
Fuse: 16
-
Voltage: 220-240 V
-
Minimum voltage: 220 V
-
Maximum voltage: 240 V
-
Frequency: 50; 60
-
Minimum frequency: 50
-
Maximum frequency: 60
-
Length of connection cable: 175.0 cm
-
Plug type: Schuko/Gardy.with earthing
-
Depth product with door open (90°): 128.1 cm
-
Height of the interior: 23.1 cm
-
Width of the cooking space: 49.3 cm
-
Depth of the interior: 40.2 cm
-
Height of the device: 45.6 cm
-
Width of the device: 75.6 cm
-
Device depth: 53.2 cm
-
Height of packaged device: 60.5 cm
-
Width of packaged device: 69.5 cm
-
Depth of packaged product: 87.5 cm
-
Minimum niche height: 44.2 cm
-
Maximum niche height: 45 cm
-
Minimum niche width: 72.2 cm
-
Maximum niche width: 73 cm
-
Niche depth: 55 cm
-
Net weight: 47.8 kg
-
Gross weight: 56.0 kg
-
Operating modes: Defrosting, drying, proofing level, hot air, microwave, low-temperature cooking, warming up food, convection grill, keeping warm
-
Energy-intelligent device, can optimize consumption behavior (2017/1369/EU): No
-
Wireless communication possible: Yes, in the device Built-in
-
Network broadband technology: Not applicable
-
SIM card slot available: No
-
Camera present in the device: No
-
Communication technology used: WiFi
-
Type of interface for control: LAN
-
Possibility of remote upgrade: Yes
-
Possibility of remote update for maintenance: Yes
-
Possibility of voice control: Yes, with optional accessories
-
Type of interior lighting: LED linear light
-
Baking tray guide: Grid
-
Lockable door: No
-
Time functions: Start and Stop
-
Type of door opening: Button
-
Automatic program: Yes
-
Restoration function: No
-
Electronic clock: Yes
-
Display on the panel: Digital display, plain text display, TFT
-
Additional operating mode grill: Yes
-
Additional hot air operating mode: Yes
-
Top and bottom heat: No
-
Automatic switch-on safety lock available: Not applicable
-
Clock: No
-
Presence of a complete text display: No
-
Interior lighting location: left
-
Cooking chamber material: Stainless steel
-
Integrated cleaning system: Hydrolytic
-
External information system: No
-
Side rails/shelves: Hanging rack
-
Time control: No timer
-
