Manufacturers:
Gaggenau
- Frameless for flush installation
- Flex function for combining the rectangular cooking surfaces
- Free placement of cookware within the interconnected cooktops with automatic extension up to 30 cm wide
- Cooking sensor function for temperature control in pots
- Professional cooking function for dividing the cooktop into defined power zones
further details
- Frameless for flush installation
- Flex function for combining rectangular cooktops
- Free placement of cookware within the interconnected cooktops with automatic extension up to 30 cm wide
- Cooking sensor function for temperature control in pots and pans
- Professional cooking function for dividing the cooktop into defined power zones
- Frying sensor function for temperature control in pans
- Twist-pad operation with removable magnetic knob
- Application-related control of all functions via two-color display
Cooking zones
- 2 Flex induction cooktops 23x20 cm (2200 w, with booster 3700 w), interconnected 23x40 cm (3300 w, with booster 3700 w), with automatic extension up to 30x30 cm (3300 w, with booster 3700 w).
- 2 Flex induction cooktops 23x20 cm (2200 w, with booster 3700 w), interconnected 23x40 cm (3300 w, with booster 3700 w), with automatic extension up to 30x30 cm (3300 w, with booster 3700 w).
Operation
- Twist-pad operation with removable magnetic toggle.
- User-friendly operation with two-color display (white / orange).
- Marking of cooking zones and cooking surfaces.
- Electronic control in 17 power levels.
Equipment
- Flex function for rectangular cooking surfaces.
- Professional cooking function.
- Cooking sensor function (when using the cooking sensor ca 060 300).
- Roast sensor function.
- Booster function pots.
- Booster function for pans.
- Keep warm function.
- Stopwatch.
- Automatic cooking time up to 99 minutes.
- Short time alarm.
- Options menu.
- Energy management.
- Cooktop-based ventilation control (with matching hood).
- Home network integration for digital services (Home Connect) wirelessly via WiFi.
- The use of the Home Connect function depends on the Home Connect services, which are not available in every country. For more information, visit home-connect.com.
Security
- Main power switch.
- Power indicator.
- Pot detection.
- 2-stage residual heat indicator.
- Child safety lock.
- Safety shutdown.
Planning information
- Installation is suitable in countertops made of stone, synthetic material or solid wood. Heat resistance and waterproof sealing of cut edges must be considered. For other materials, consult the countertop manufacturer regarding use.
- Only suitable for iron magnetic cookware. For optimal temperature distribution, cookware with sandwich bottom is recommended.
- The wok pan wp 400 001 cannot be used on this unit.
- Device is to be fixed from below.
- Weight of appliance: approx. 18 kg.
Connection data
- Total connected load 7.4 kW.
- Connection cable 1.5 m without plug.
- Power standby/display off 0.5 W.
- Power standby/network 2.0 W.
- Please follow the instructions in the user manual if you want to switch off the WiFi function.
Product safety information
Manufacturer information:
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
Bayern
München, Deutschland, 81739
www.bsh-group.com
https://www.bsh-group.com
-
Product series200 series
-
Design: Built-in
-
Controlelectronic
-
Controls: illuminated, magnetic knobs, front, cylinder knobs
-
Power source: Electric
-
Control position: Front
-
Main surface material: Glass ceramic
-
Color deviceblack
-
Basic color of the productblack
-
Frame design: Flush
-
Connected load: 7400 W
-
Voltage: 220-240 V
-
Frequency: 50-60 TPU00040
-
Approval certificates: aenor, CE
-
Length connection cable150 cm
-
Plug type: without plug
-
Device width: 79,3 cm
-
Device height5,6 cm
-
Device depth51,3 cm
-
Packed unit height13 cm
-
Width of packed unit95 cm
-
Depth packed product60 cm
-
Minimum niche height49 cm
-
Minimum niche width78 cm
-
Niche depth5,6 cm
-
Net weight: 17,8 kg
-
Gross weight: 19,2 kg
-
Application of EU energy consumption directive: No
-
Energy consumption of the 2nd heating element per kg: 185.0 Wh/kg
-
Energy intelligent device, can optimize consumption behavior (2017/1369/EU): No
-
Wireless communication possible: Yes, built in the device
-
Network broadband technology: Not applicable
-
SIM card slot available: No
-
Control interface typelAN
-
Remote upgrade possibility: No
-
Possibility of remote update for maintenance: Yes
-
Automatic program: No
-
Cooking zone position: front left
-
Position of 2nd cooking zone: center left
-
Position of 3rd cooking zone: rear left
-
Position of the 4th cooking zone: center rear
-
Position of the 5th cooking zone: rear right
-
Position of the 6th cooking zone: center right
-
Position of the 7th cooking zone: front right
-
Position of the 8th cooking zone: front center / central
-
Position of the 9th cooking zone: central
-
Type of 2nd cooking zoneinduction
-
Type of 6th cooking zoneinduction
-
Dimensions of the 2nd cooking zone40 cm
-
Dimensions of the 6th cooking zone40 cm
-
Power of the 2nd cooking zone: 2.2 W
-
Power of the 6th cooking zone: 3.3 W
-
Operating indicator light: No
-
Control: Stepless energy control
-
Cover typewithout
-
Ignition: No
-
Residual heat indicator: Separate
-
Main switchyes
-
Safety devices: Key Lock, Child Lock, Power Management Function, Safety Timeout
-
Electronic clock: Yes
-
Possibility to combine cooking zones/areas: No
