- 4 climate zones incl. 2 fresh food drawers near 0 °c
- Height adjustable shelves made of safety glass
- Door shelves with aluminum profiles
- Damped door retraction system allows smooth and controlled closing
- Usable capacity total 223 liters
further details
- 4 climate zones incl. 2 fresh food drawers near 0 °c
- Height adjustable safety glass shelves
- Door shelves with aluminum profiles
- Damped door retraction system allows for smooth and controlled closing
- Usable capacity total 223 liters
Operation
- Electronic temperature control with digital display.
- Sensor buttons.
Technical features
- automatic defrost with defrost water evaporation.
- Damped door retraction system from 20° door opening angle, integrated in the door hinge.
- alarm in case of open door or malfunction.
- Vacation mode.
- Home network integration for digital services (Home Connect) wireless via WiFi.
- the use of the Home Connect function depends on the Home Connect services, which are not available in every country. For more information, visit home-connect.com.
Cooling
- Fast cooling.
- Temperature adjustable from +3 °c to +8 °c.
- 2 height-adjustable safety glass shelves, 1 of which is extendable.
- 1 shelf.
- Wine and champagne rack for 4 bottles, fully foldable.
- 1 large door rack with aluminum profile for bottles. Bottle holder, sliding.
- 1 door rack with aluminum profile.
- Bright interior lighting with glare-free LEd lighting element, integrated on the side.
- Usable capacity 101 liters.
Fresh cooling close to 0 °c
- 1 fully extendable fresh cooling drawer close to 0 °c, illuminated.
- Humidity manually adjustable.
- Ideal for fruit and vegetables.
- Ideal for meat, fish and poultry.
- Useful capacity 55 liters.
Freezing
- No-frost technology with fast freezing.
- Temperature adjustable from -14 °c to -24 °c.
- 4-star freezer compartment.
- defrost aid.
- Freezing capacity 7 kg /24 hrs.
- Storage time in case of malfunction 8 hrs.
- 3 freezer drawers, 1 extra large.
- 2 safety glass shelves.
- Useful capacity 67 liters.
Consumption data
- Energy efficiency class d on a scale of efficiency classes from a to G.
- Energy consumption 201 kWh/year.
- Noise value 37 dB (a) re 1 pW.
Planning information
- Flat hinge.
- Door hinge right, changeable.
- Door opening angle 115°, fixable to 90°.
- Max. permissible door front weight:
- Door top 19 kg.
- Door bottom 19 kg.
connection data
- Total connected load 0.090 kW.
- connection cable 2.3 m with plug.
Product safety information
Manufacturer information:
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
Bayern
München, Deutschland, 81739
www.bsh-group.com
https://www.bsh-group.com
Drop "Shop: DE: Produktseite: LoadBee" could not be rendered:
Syntax error in template "string:{assign var="drop" value=kkDropperHelper..." on line 5 "{/ if}" - Unexpected " ", expected one of: "id, name"
-
Product series200 series
-
Product categorybottom freezer
-
Control systemelectronic
-
Controlscontrols : Superswitch freezing, Superswitch cooling, Temperature display for cooling, Warning functions freezer section, Warning signal freezing malfunction, Warning signal door open
-
Construction built-in
-
type of installation: fully integrable
-
decorable: Not possible
-
Color device: Not applicable
-
connected load: 90 W
-
fuse protection: 10
-
Voltage: 220-240 V
-
Frequency50 TPU00040
-
approval certificatescE
-
Length of connection cable230 cm
-
Type of plugschuko/Gardy. with grounding
-
Net capacity: 223 l
-
Gross capacity refrigerator: 183 l
-
Gross capacity freezer section: 84 l
-
Unit height177,2 cm
-
Appliance width55,8 cm
-
Appliance depth54,5 cm
-
Product depth with door open (90°)114 cm
-
Door hinge: Changeable to the right
-
Height adjustable feetno
-
Height packed unit184 cm
-
Width packed unit61 cm
-
Depth packed product64 cm
-
Minimum niche height177,5 cm
-
Maximum niche height177,5 cm
-
Minimum niche width56 cm
-
Maximum niche width56 cm
-
Niche depth55 cm
-
Net weight: 75,0 kg
-
Gross weight: 80,4 kg
-
Product type: 2 doors
-
type of defrosting technology (4-star compartment) (eu 2017/1369): automatic
-
Recommended temperature (4-star compartment) (eu 2017/1369): -18 °c
-
Compartment volume (4-star compartment) (eu 2017/1369): 67.0 l
-
Total volume of the freezer compartments (eu 2017/1369): 67 l
-
Sum of the volumes of the cold storage compartments (eu 2017/1369): 156 l
-
Total volume of the product (eu 2017/1369): 223 l
-
type of defrosting technology (cold storage compartment) (eu 2017/1369): automatic
-
Volume of the compartment (cold storage compartment) (eu 2017/1369): 55.0 l
-
average energy consumption in kilowatt hours per year (kWh/a) (eu 2017/1369): 201 kWh/a
-
Energy efficiency index (eu 2017/1369): 79.5
-
Quick freeze" function (eu 2017/1369): Yes
-
Freezing capacity (four-star compartment) (eu 2017/1369): 7.0 kg/24h
-
Compartment volume (fresh food storage compartment) (eu 2017/1369): 101.0 l
-
type of defrosting technology (fresh food storage compartment) (eu 2017/1369): automatic
-
type of light source (eu 2019/1805): LEd
-
Low noise refrigerator: no
-
Maximum ambient temperature (eu 2017/1369): 43 °c
-
Minimum ambient temperature (eu 2017/1369): 10 °c
-
Airborne sound emissions (eu 2017/1369): 37 dB(a) re 1 pW
-
Product excluded from the scope for "low noise appliance" and "wine storage cabinet" (eu 2017/1369): No
-
QR code (eu 2017/1369): HTTPS://EPREL.EC.EUROPa.EU/QR/260900
-
Wine storage cabinet only: No
-
Control function ?Winter switching" for combi unit (eu 2017/1369): No
-
Energy smart appliance, can optimize consumption behavior (2017/1369/EU): No
-
wireless communication possible: Yes, built into the unit
-
Network broadband technology: Not applicable
-
SIM card slot availableno
-
Communication technology usedwiFi
-
type of interface for control: LaN
-
Remote upgrade possibilityno
-
Possibility of remote update for maintenance: Yes
-
Camera present in deviceno
-
Material usedsafety glass
-
Temperature display refrigeratordigital
-
Temperature display freezerdigital
-
Fast freezing functionyes
-
Door open indicator freezeryes
-
Temperature adjustable freezeryes
-
Included accessories: 2 x cold battery, 3 x egg rack, 1 x wine and champagne rack, 1 x ice cube tray
-
Defrost water drying: No
-
Internal fan cooling section: No
-
Adjustable temperatureyes
-
Furniture door mounting: Fixed mounted
-
Motorized automatic ice makerno
-
Bottle rackyes
-
lockable doorno
